Expiration Gas Metabolism Monitor
Cpex-1

Expiratory gas analyzer offering high accuracy and reproducibility

Cpex-1 can accurately measure data in a wide range of fields, from assessing basal metabolism at rest to creating exercise prescriptions for cardiac rehabilitation, evaluating the effects of treatment for cardiac and respiratory diseases, and measuring exercise tolerance in athletes.

Dimensions



Main unit: 20(W)×30(D)×18.5(H)cm

Dedicated cart: 64.4(W)×66(D)×91.2(H)cm

Weight 28kg
Power AC100V,60/60Hz
Power consumption 30VA
Operating temperature 10-40℃
level of humidity 30-75% (no condensation)
configuration

・Cpex-1 main unit

・Syringe for ventilometer calibration

・Exhalation masks (2 pcs)

・Ventilometer

・Sampling tube

・Isolation transformer

・Data processing PC (OS: Windows)

・Monitor

・Dedicated cart

・Calibration gas

・Isolation transformer

Main Features

High-precision Measurement

The "Sample Gas Transfer Time Automatic Assurance System" enables highly accurate measurements. Equipped with high-response O2 and CO2 sensors and a pneumotachometric ventilation meter, it continuously monitors ventilation flow rate, O2 concentration, and CO2 concentration on a breath-by-breath basis (with real-time display capability). This ensures reliable measurements without errors, regardless of exercise intensity.

Outstanding Operability

With one-click calibration and automated analysis features, accurate and reproducible data can be obtained by users of all skill levels, from beginners to experts. The previously cumbersome calibration process is now completed with a single click. Scale adjustments and parameter changes can also be made in real time during measurement. For determining the AT point, a key indicator for exercise prescription, the device provides automatic analysis support and triangular ruler visual displays, making it easy even for less experienced users to determine accurately.

Report Evaluation Based on the Latest Reference Values

The reference values used for evaluation in the final report are authorized for commercial use by the original authors and provide the only standard in Japan for assessing the exercise capacity of test subjects.
Reference Source: J Cardiology 2013:61:71-78
The individual values from the comprehensive report are compared and evaluated against reference values for healthy individuals, categorized by age and gender.
Reports Include:
・Dr. Wassermann's Standard 9 Reports
・Cpex-1 Original 3 Reports
・Exercise Guidance Report
・Nutrition Management Report
This system has been adopted as the practical training device for cardiopulmonary exercise testing at exercise prescription seminars hosted by JHC (Japan Heart Club).
